The Peplink MAX HD2 MBX CAT 12 is a high-performance dual-cellular SD-WAN router designed to deliver reliable connectivity for transportation, enterprise networking, industrial applications, and mission-critical mobile deployments. Equipped with two independent LTE Advanced Pro Cat 12 modems, it enables simultaneous cellular connections across supported mobile carriers, helping organizations maintain dependable internet access and flexible network redundancy.
Powered by Peplink SpeedFusion technology, the MAX HD2 MBX CAT 12 combines bandwidth bonding, seamless failover, and WAN Smoothing to improve network resilience. Its rugged, fanless design, Gigabit Ethernet connectivity, dual-band Wi-Fi, and optional PoE+ capabilities make it a versatile solution for demanding mobile and remote networking environments.
Key Features:
Dual LTE Advanced Pro Cat 12 Connectivity: Two independent embedded 4G LTE Cat 12 modems support simultaneous cellular connections across compatible networks, providing flexible multi-carrier connectivity and WAN redundancy.
High-Speed LTE Performance: Each Cat 12 modem supports theoretical download speeds of up to 600 Mbps and upload speeds of up to 150 Mbps, depending on carrier capabilities and network conditions.
SpeedFusion Bandwidth Bonding: Combines multiple WAN connections through Peplink SpeedFusion technology to improve bandwidth utilization and connection resilience.
Seamless Hot Failover: Helps maintain active VPN sessions when a cellular or wired connection becomes unavailable, reducing disruptions to critical business applications.
WAN Smoothing: Uses redundant packet transmission across multiple WAN connections to help minimize packet loss and improve the reliability of real-time communications.
Four SIM Slots: Provides two Mini-SIM slots per cellular modem, enabling flexible carrier selection and backup configurations.
Gigabit Ethernet Connectivity: Features two dedicated Gigabit Ethernet WAN ports, one configurable Gigabit Ethernet WAN/LAN port, and eight Gigabit Ethernet LAN ports for connecting wired networks and local equipment.
Dual-Band Wi-Fi 5: Integrated 802.11ac Wi-Fi with 2×2 MIMO supports simultaneous 2.4 GHz and 5 GHz operation for wireless access point and Wi-Fi WAN connectivity.
Up to 2.5 Gbps Router Throughput: Delivers high-performance routing for enterprise networking, multi-WAN operations, and demanding mobile deployments.
SpeedFusion VPN Performance: Supports up to 600 Mbps VPN throughput without encryption and up to 500 Mbps with 256-bit AES encryption.
Dual USB WAN Connectivity: Two USB interfaces provide additional WAN connectivity options through compatible external devices.
Flexible PoE+ Connectivity: Supports up to eight 802.3at PoE+ LAN outputs when properly powered and activated, simplifying power delivery to compatible network equipment.
Integrated GPS: Enables location monitoring and fleet tracking for transportation and mobile networking applications.
Ignition Sensing: Supports integration with vehicle power systems for managed startup and shutdown behavior.
Rugged Fanless Design: A durable industrial-grade metal enclosure with passive cooling, designed for demanding mobile and industrial environments.
Wide Operating Temperature Range: Supports operation from -40°C to 65°C (-40°F to 149°F).
InControl 2 Cloud Management: Enables centralized monitoring, remote configuration, and network administration through Peplink's cloud-based management platform.
Applications:
The Peplink MAX HD2 MBX CAT 12 is designed for organizations requiring dependable multi-carrier connectivity across mobile, enterprise, and industrial environments.
Transportation and Fleet Management: Maintain connectivity for vehicle-mounted networking equipment, fleet tracking, and operational communications.
Public Safety and Emergency Operations: Support mobile networking and field communications using compatible commercial cellular services.
Industrial IoT and Remote Monitoring: Connect industrial controllers, monitoring equipment, and distributed IoT devices.
Enterprise Branch Connectivity: Provide cellular WAN redundancy and reliable connectivity for distributed business locations.
Construction and Temporary Worksites: Establish flexible network connectivity where fixed broadband services are unavailable.
Mobile Surveillance and Security: Connect compatible IP cameras, security systems, and networking equipment using Ethernet and optional PoE+ outputs.
Broadcasting and Live Events: Support remote networking and video transmission through multiple cellular connections.
Reliable Dual-Cellular Networking for Demanding Operations
The Peplink MAX HD2 MBX CAT 12 combines dual LTE Advanced Pro modems, SpeedFusion technology, Gigabit Ethernet connectivity, and flexible power options in a rugged industrial networking platform. Designed for demanding mobile and enterprise deployments, it helps organizations improve network availability, simplify remote management, and maintain dependable connectivity across multiple cellular providers.
Full eight-port PoE+ operation requires two compatible 54V DC power inputs and appropriate PoE activation. Optional accessories and advanced licensing are subject to the purchased configuration.
