The Peplink MAX HD1 Dome Pro 5G (FirstNet Certified) is a rugged outdoor 5G SD-WAN router engineered to provide reliable cellular connectivity for transportation, maritime operations, public safety, and industrial deployments. Featuring an embedded 5G modem, integrated 4×4 MIMO cellular antennas, and dual-band Wi-Fi 6, it delivers a compact networking solution for demanding mobile and outdoor environments.
Unlike conventional routers that require long external antenna cables, the MAX HD1 Dome Pro integrates its cellular modem and antennas within the same enclosure, minimizing RF cable loss and simplifying installation. With Peplink SpeedFusion technology, IP67-rated protection, and Power over Ethernet support, it helps organizations maintain dependable connectivity in locations where traditional networking equipment may be impractical.
Key Features:
-
Integrated 5G Cellular Connectivity: A built-in 5G modem supports Non-Standalone (NSA) Sub-6 GHz networks with 4G LTE fallback, providing flexible connectivity across compatible cellular carriers.
-
FirstNet Certified: Certified for FirstNet, AT&T, T-Mobile, and Verizon, making this configuration suitable for eligible U.S. public-safety and enterprise connectivity deployments.
-
4×4 MIMO Cellular Antennas: Four integrated cellular antenna elements support 4×4 MIMO operation, improving installation efficiency while minimizing losses associated with external RF cables.
-
Dual-Band Wi-Fi 6: Integrated 802.11ax Wi-Fi with 2×2 MIMO supports simultaneous 2.4 GHz and 5 GHz operation, providing wireless access point and Wi-Fi WAN capabilities.
-
SpeedFusion Technology: Supports SpeedFusion Hot Failover, WAN Smoothing, and Bandwidth Bonding to improve connection resilience when configured with compatible WAN links and SpeedFusion endpoints.
-
Redundant SIM Connectivity: Two built-in physical SIM slots enable flexible carrier selection and cellular connection redundancy.
-
RemoteSIM and eSIM Support: Supports Peplink SIM Injector, RemoteSIM, and compatible eSIM solutions for flexible remote SIM management and cellular service provisioning.
-
IP67-Rated Outdoor Protection: The rugged enclosure provides protection against dust and water when properly installed with the supplied waterproof Ethernet components.
-
Single-Cable PoE Installation: Supports 802.3at PoE+ input, enabling power and Ethernet connectivity through a single cable.
-
PoE Output Capability: The included Ethernet splitter provides an 802.3af PoE output for powering compatible external networking equipment.
-
Gigabit Ethernet Connectivity: Features one Gigabit Ethernet LAN interface, with additional connection flexibility through the included Ethernet splitter.
-
Integrated GPS Functionality: A built-in GPS antenna supports location monitoring and fleet tracking for mobile networking applications.
-
Flexible Mounting Options: The compact dome-shaped enclosure supports multiple installation configurations, including compatible pole, wall, and outdoor mounting systems.
-
Industrial-Grade Durability: Designed to operate from -40°C to 65°C (-40°F to 149°F), with certifications covering applicable railway and electromagnetic compatibility standards.
-
InControl 2 Cloud Management: Enables centralized device monitoring, remote configuration, and network administration through Peplink's cloud management platform.
Applications:
The Peplink MAX HD1 Dome Pro 5G is designed for organizations requiring reliable high-speed cellular connectivity in outdoor, mobile, and demanding environments.
-
Public Safety and Emergency Services: Support eligible FirstNet communications for emergency response vehicles, mobile command centers, and field operations.
-
Transportation and Fleet Management: Provide 5G connectivity for vehicle-mounted networking equipment, fleet monitoring, and operational communications.
-
Maritime Operations: Enable cellular connectivity for vessels and marine installations operating within compatible mobile network coverage.
-
Industrial IoT and Remote Monitoring: Connect monitoring systems, industrial equipment, and remote facilities through cellular networks.
-
Construction and Temporary Worksites: Establish network connectivity where fixed-line broadband infrastructure is unavailable or impractical.
-
Outdoor Wi-Fi Deployments: Provide local wireless connectivity through integrated Wi-Fi 6 for compatible devices and applications.
-
Mobile Healthcare: Support networking equipment and connected systems in ambulances, mobile clinics, and medical transport vehicles.
Reliable 5G Connectivity in a Compact Outdoor Design
The Peplink MAX HD1 Dome Pro 5G combines integrated 5G cellular connectivity, Wi-Fi 6, SpeedFusion technology, and IP67-rated protection in a compact outdoor networking solution. With FirstNet certification, flexible installation options, and centralized cloud management, it provides a versatile platform for organizations that need reliable connectivity in challenging mobile and outdoor environments.
FirstNet connectivity requires eligible service and compatible coverage. Advanced SpeedFusion functions may require applicable licensing and a compatible endpoint. Optional SIM Injector and mounting accessories are available separately.
